DIMENSION SKETCH 68-13 AND 68-14 (STEEL SIDES)
DIMENSION SKETCH SCAN 68-13 AND 68-14LB (LOW BASE)
A
Centre rear outlet
B
Height to the beginning of the
connecting piece at top outlet
C
Centre of fresh air intake
All measurements are in millimeters
A
Centre rear outlet
B
Height to the beginning of the
connecting piece at top outlet
C
Centre of fresh air intake
All measurements are in millimeters
