Stove:
Path:
Articlenumber:
Material:
Date:
Constructed/Changed by:
SCAN A/S
DK-5492 Vissenbjerg©
Drawing
number:
Name:
C:\Working Folder\Designs\Scan 80\90580075.idw
90580075Scan 80 med knærør 10-09-2018
ken
Scan 80
Weight:
Area:
N/A N/A
11
REQUIREMENTS FOR CHIMNEY
The chimney must have a minimum internal diameter of 148 mm and have a T400 designation,
with G for the soot fire test. The length should be min. 4 metres.
If you opt to connect the stove with an elbow pipe, you should use a curved elbow,
as this gives a better draught.
If you connect the stove with a sharp elbow pipe, the cleansing lid must be placed in the
vertical part so that the horizontal part can be cleaned through here.
If the chimney is fitted with a smoke extractor, it must be possible to adjust it to a suitable draft.
The requirements to the chimney and the flue pipe in terms of safety distances must be met.
¬ Choosing the wrong length or diameter of steel chimney could impair functionality
¬ Always comply exactly with the instructions provided by the steel chimney supplier
POSITIONING THE STOVE AT A NON-FLAMMABLE WALL
There are no demands concerning the distance to non-flammable materials, but we recommend a distance of 50 mm in order to
facilitate the cleaning of the stove, the flue pipes and the chimney and to prevent possible damages to the wall.
DISTANCE TO FURNITURE
Distance to furniture: min. 800 mm.
You should however assess whether furniture or other items might become excessively dry due to being too close to the stove.
Distance to ceiling (High Top): 350 mm.
SAFETY DISTANCE
European, national and local regulations concerning safety distances for wood-burning stoves must be complied with.
