5
* The stove can take logs up to 30 cm (horizontally placed).
** Intermittent operation in this context means normal use of
a wood-burning stove. In other words, you should let the fire
die down until only the embers are left before refuelling.
The Scan 80-series is produced in accordance with type
approval for the product, which also covers the product’s
Assembly and Instruction Manual.
The Declaration of Performance (DoP) is available from
www.scan-stoves.com
Tested in accordance with EN 13240
CO Emission at 13% O
2
0,06 %
CO
Emission at 13% O
2
800 mg/Nm
3
Dust @ 13% O
2
<6 mg/Nm
3
No
x
@ 13% O
2
81 mg/Nm
3
Efficiency 84 %
Energy efficiency index 112
Energy efficiency class A+
Nominal output 6 kW
Chimney temperature EN 13240 195 °C
Temperature in flue conn. piece 233 °C
Amount of smoke 6,3 g/sec
Negative pressure EN 13240 12 Pa
Recommended negative pressure
in flue connecting piece
17-20 Pa
Required combustion air supply 19-25 m
3
/h
Fuel Wood
Fuel consumption 1,9 kg/h
Amount of fuel required to light 1,5 kg
Amount of fuel, max. 2,25 kg
Materials
Steel plate
Cast iron
Galvanised sheet
Vermiculite
Surface treatment Senotherm
Max. log length 25 cm*
Weight Scan 80-1/2 ca. 104,4 kg
Weight Scan 80-3/4 ca. 110,0 kg
Flue conn. piece internal diameter 144 mm
Flue conn. piece external diameter 148 mm
Fresh air connection piece
external diameter
100 mm
Approval type Intermittent**
TECHNICAL DATA AND DIMENSIONS
EN test was carried out on the installation with an un-insulated
elbow pipe shown in the assembly manual for Scan 1008 on
page 11.
(Reference to EN 13240: 2001/A2:2004)
