NAVN:
STI:
M3 NR.:
MATERIALE:
DATO:
SIGN:
Scan A/S
DK-5492 Vissenbjerg
©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 80\90580044.idw
90580044
Scan 1008 - røgvenderplade
21-12-2017
ken
VÆGT:
AREAL:
N/A
N/A
DIMENSION:
Stove:
Path:
Articlenumber:
Material:
Date:
Constructed/Changed by:
SCAN A/S
DK-5492 Vissenbjerg
©
Drawing
number:
Name:
C:\Working Folder\Designs\Scan 80\90580033.idw
90580033
Udtagning af vermiculitte røgvender
19-05-2017
jwa
Scan 80
Weight:
Area:
3,73 kg
503879 mm^2
25
CLEANING THE GLASS
Our wood-burning stoves are designed to prevent serious soot build-up on the glass. The best way to achieve this is to make sure
you have a good supply of combustion air. It is also very important that the wood is dry and the chimney correctly dimensioned.
Even if you operate the stove in accordance with our instructions, a slight film of soot may still accumulate on the glass.
You can
easily remove this film by wiping the glass down with a dry cloth and then with a cloth dampened with glass cleaner.
¬ Please note that the glass cleaner is not to get into contact with the gaskets, as this can discolour the glass permanently
¬ The glass cleaner must not come into contact with the painted surfaces, as these can be damaged
REMOVING THE BAFFLE PLATE AND THE BAFFLE UNIT
Be very careful when removing the baffle plate from the stove.
After the baffle plate has been removed, the baffle unit can be dismounted.
Lift up the baffle unit a little and
tip it slightly backwards until it is
free of the hole.
Then slowly pull out the unit, until
it is free of the rear rails
Baffle plate Baffle unit
