29
5
NAVN:
STI:
DIMENSION:
MATERIALE:
DATO:
SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg
©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan85\90585040.idw
90585040
Afmontage brændkammerforing
23-11-10
BC
Scan 85
VÆGT:
AREAL:
N/A
N/A
NAVN:
STI:
DIMENSION:
MATERIALE:
DATO:
SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg
©
TG.NR:
EMNE:
C:\Working Folder\Designs\Scan85\90585041.idw
90585041
Afmontage brændkammerforing nederste rygplade
23-11-10
BC
Scan 85
VÆGT:
AREAL:
N/A
N/A
In order to remove the lower back plate of the combustion chamber, lift the cast iron bottom upwards and forwards.
This will release the back plate, which can then be removed from the combustion chamber
Cast iron bottom
REMOVAL OF BAFFLE PLATES AND COMBUSTION CHAMBER LINING
CLEANING THE GLASS
Our wood-burning stoves are designed to prevent serious soot build-up on the glass. The best way to achieve this is to make sure
you have a good supply of combustion air. It is also very important that the wood is dry and the chimney correctly dimensioned.
Even if you operate the stove in accordance with our instructions, a slight film of soot may still accumulate on the glass.
You can
easily remove this film by wiping the glass down with a dry cloth and then with a cloth dampened with glass cleaner.
¬ Please note that the glass cleaner is not to get into contact with the gaskets, as this can discolour the glass permanently
¬ The glass cleaner must not come into contact with the painted surfaces, as these can be damaged
DISPOSAL OF STOVE PARTS
Steel/cast iron Send for recycling
Glass Dispose of as ceramic waste
Combustion chamber lining Vermiculite, ceramic stone and chamotte are not recyclable. Dispose of as waste
Baffle plate Vermiculite, ceramic stone and chamotte are not recyclable. Dispose of as waste
Gaskets Dispose of as waste
