5
TECHNICAL DATA AND DIMENSIONS
*
Test in compliance with EN 13240
CO Emission at 13% O
2
0,06 %
CO
Emission at 13% O
2
801 mg/Nm
3
Dust @ 13% O
2
7 mg/Nm
3
No
x
@ 13% O
2
87 mg/Nm
3
Efficiency 78 %
Energy efficiency index 103
Energy efficiency class A
Nominel output 8 kW
Chimney temperature EN 13240 272 °C
Temperature in flue conn. piece 326 °C
Amount of smoke 7,8 g/sek
Sub-pressure EN 13240 12 Pa
Recommended sub-pressure in
connecting piece
18-20 Pa
Required combustion air supply 21,6 m
3
/h
Fuel Wood
Fuel consumption 2,5 kg/h
Amount of fuel 2,2 kg
Amount of fuel, max. 2,6 kg
Materials
Steel plate
Cast iron
Galvanised sheet
Ceramic stone/vermiculite
Surface treatment Senotherm
Max. wood length
(horizontal position)
30 cm
Max. wood length
(vertical position)
50 cm
Weight Scan 85 series ca. 204-220 kg
Connecting piece internal diameter 144 mm
Connecting piece external diameter 148 mm
Fresh air connection piece external diameter 100 mm
Approval type Intermittent fuelling*
Intermittent operation in this context means normal use of
a wood-burning stove. In other words, you should let the fire
die down until only the embers are left before refueling.
This stove is produced in accordance with type approval for
the product, which also covers the product’s Assembly and
Instruction Manual.
The Declaration of Performance (DoP) is available from
www.scan-stoves.com
