Fuel system
OPM 320 en-GB 45
© Scania CV AB 2019, Sweden
3.
Remove the flame arrestor housing bracket
and screws.
4. Remove the upper part of the flame arrestor
housing and the throttle.
5. Remove the flame arrestor.
6. Clean the insert with degreasing agent. Re-
move dirt with a soft brush.
7. Rinse the insert with hot water.
8. Blow out any remaining water with com-
pressed air.
