#SC 45TW-SS 10 – 110202 Page 29 of 40
Spare Part List - SC 45TW - Stainless Steel
Pos. Part No. Qty. Description
27 104713 8 Bolt
28 40012 1 Gear
29 40031 1 Hub
30 40026 3 Bearing
31 1 Precision Ball
32 120302 1 Retaining Ring
33 40197 1
Worm Gear Assembly Incl. pos 31
34 40015 1 Hub
35 105098 1 Bolt
36 40145 1 Gear
37 40016 1 Gear
38 110442 2 O-ring
39 110454 2 O-ring
40 40148 1 Stator
41 40028 1 Bearing
42 20018-xx 1
Turbine Cone Acc. to order
43 40011-xx 1
Turbine Acc. to order
44 40040 1 Nut
45 40036 1 Bearing
46 40046 1 Top Bearing
47 40048 1 Adapter 2” BSP
40081-xx 1 Connection Adapter Optional See page 7
48 40088 2 Locking Plate
49 104444 8 Bolt
50 70075 1 Strainer
51 70098 1 Retaining Ring
