#SC 45TW-SS 10 – 110202Page 32 of 40
12.1. Exploded Drawing - Rubber Bumper
This kit can be ordered as part no. “RB 45”
Spare Part List - Rubber Bumper
Pos. Part No. Qty. Description
1 40071 2 Hose clamp
2 41089-2 1 Rubber protection
3 40070 1 Rubber bumper bottom
4 41082 3 Pipe
5 106105 3 Washer
6 120426 3 Bolt
