5. Performance Data
Performance data: The table below shows the flow and effective jet length
(radius) for each combination of inlet pressure and nozzle diameter. Other
nozzles and maximum jet length available upon request.
Supply pressure MPa (Bar)
0,6 (6) 0,8 (8) 1,0 (10) 1,2 (12)
Nozzle size
Flow
[m³/h]
Jet
length
[m]
Flow
[m³/h]
Jet
length
[m]
Flow
[m³/h]
Jet
length
[m]
Flow
[m³/h]
Jet
length
[m]
2 x Ø11mm 22 15 25 17 28 19 31 20
2 x Ø12mm 25 15 29 17 32,5 19 36 20
2 x Ø14mm 30 15 35 17 38,5 19 42,5 20
2 x Ø16mm 34 14 38 16 42 18 45 20
2 x Ø18mm 35 13 40 15 45 17 49 19
