11. Spare Part List - SC 45TW
List dated 2011-02-02
NOTE! Spare parts number may be changed without prior notice. Final spare
parts numbers will be issued for “ship set manual”.
Depending on nozzle size there is some parts that differ. See chapter “13. Basic
Settings” on page 33 for information about your specific settings.
Spare Part List - SC 45TW - Stainless Steel
Pos. Part No. Qty. Description
1 50155-xx 2 Nozzle (“xx” is nozzle diameter)
2 105087 2 Bolt
3 50156-085-S 2 Nozzle Tube
4 50158 2 Flow Guide
5 105089 2 Bolt
6 40142-25-3 1 Nozzle Housing
7 40149 1 Gear
8 40037-2 2 Ball Bearing
9 40146 1 Cover
10 104726 6 Bolt
11 40055 1 Housing
12 110425 2 O-ring
13 40035 1 Bearing Ring
14 40147 1 Gear
15 104741 6 Bolt
16 40098 1
Turbine Shaft Assembly Incl. pos 17
17 1 Precision Ball
18 1 Bearing
19 1 Bearing
20 40062 1
Bearing Sleeve Assembly Incl. pos 18, 19
21 105096 1 Bolt
22 40099 1 Bearing Sleeve Assembly
23 1 Bearing
24 1 Bearing
25 104726 6 Bolt
26 40004 1 Bottom Plate
