Installation instructions 4 - 12
Doc.nr : Rc400-Manuale_v20_e.doc
General technical data :
For dimensions, see chapter 2 - "General system description".
Portable control unit:
Battery pack : 7.2 VDC.
Control unit effective operating time : Approx. 8 hours per charge.
Weight : 1.6 kg ( without battery pack and radio transmitter).
Weight: 1.9 kg ( with battery pack and radio transmitter).
Electronicbox:
Supply voltage ( See order ) : + 24 VDC ( +/- 20 % / max. 5% V peak to peak ).
Max. over-voltage :Approx. 33 VDC ( Fuse blows ).
Proportional functions :1 - 8 double operating proportional functions.
Dump valve drive :Max. 2,0 Ampere ( short circuit proof ).
ON/OFF drive :Max. 1,2 Ampere ( short circuit proof ).
Regulation signal disconnected with:Supply voltage + 24 VDC at 15 - 17 VDC.
Current consumption at Idle:60 mA ( Without radio receiver box ).
140 mA ( With radio receiver box ).
Total current consumption : See Danfoss catalogue for PVEO, PVEM, PVEH-current
consumption !
Sum all current consumption, i.e. all PVEM/PVEH,
ON/OFF functions, dump valve etc.
Fuses in electronics box : Plus : + 10 Amp. ( Standard car fuse / Red ).
Ground : - 30 Amp. ( Standard car fuse / Green ).
Battery charger :
Battery charger current consumption without battery pack is : » 10 - 20 mA.
Battery charger current consumption with battery pack is : » 130 - 140 mA.
Terminal voltage at battery charger terminals is : » Vehicle supply voltage.
Fuse : Glass fuse 3 Ampere ( quick ), with size 5 x 20 mm.
Location : The fuse holder ( bayonet type ) is to be found beside the connection cable.
