2 of 12 496328 Issue 2
INTRODUCTION
The 9448+ and 9448ES Alarm Control Panels are fully programmable 7 zone
control panels with Full and Part Set, designed for domestic installations.
The 9448ES is an end station version designed for domestic and small
commercial installations.
In the 9448+ the control panel comprises a single printed circuit board, with
microprocessor electronics, mounted in a Polycarbonate casing with a hinged
lid. On the outside of the lid is a backlit soft rubber keypad and a column of
LED (Light Emitting Diode) displays. Up to two optional 9427 Remote Key-
pads can be connected to the control panel and used in exactly the same
way as the keypad on the control panel. Note that the captions on the keys
have a different arrangement.
For the 9448ES the control unit comprises a single printed circuit board, with
microprocessor electronics, mounted in a steel box with a slide off lid. Up to
four 9427 remote keypads can be connected to the control unit.
Technical Specification
Operating temperature -10º to +50ºC.
Humidity 80% RH.
9448+
Dimensions h x w x d 210 x 210 x 65mm.
Weight Approx 1.1kg (without stand-by battery).
9448ES
Dimensions = h x w x d 234 x 243mm x 87mm.
Weight = Approx 3.0 kg (without stand-by battery).
Power Supply
System Power Supply 230VAC (Ambient Temp. 20 º C).
Quiescent Panel Power 50mA nominal.
Active Panel Power 150mA nominal.
9427 Remote Keypad 20mA.
9448+
Standby Battery 12 Volt, 2.1AH rechargeable lead-acid, Gel
Type battery.
Battery Space h x w x d 55 x 185 x 30mm.
9448ES
Standby Battery = 12 Volt, 7AH rechargeable lead-acid, Gel
Type battery.
9448+/9448ES
