4.3.3 Fresh water intake for washing
Fresh water
intake for
washing
Tee in downstream of the vessel's fresh water
pressure system.
The following conditions must be respected:
• The flow of the existing fresh water pump
must be min 18 lit/min.
• Flushing must always be performed with
the pressure water system ON.
Pressurized tank: Min. flow rate
must be 18-20 lit/min. at 2,5 bar.
CAUTION
Pressurized tank: Min. flow rate must be 18-20 lit/min. at 2,5 bar.
4.3.4 Brine discharge
Salt water
discharge
The salt-water drain shall be ½’’ minimum size
and it has to be preferably above the seawater
level.
Minimum size ½’’
Pre-existing salt
water discharge
(alternatively)
It is possible to use offtakes from existing
apparatuses, provided that:
• It is not the engine cooling water drain or
apparatuses that drain out water with
elevated pressure.
INSTALLATION NOTES
If the discharge is upon the seawater level, it is recommended to provide a valve along the pipe.
CAUTION
Do not run the system when the discharge valve is closed.
