20 GB
f. Keep cutting edges sharp and clean. Properly
maintained cutting tools with sharp cutting edges
jam less often and are easier to control.
g. Use power tools, accessories, and equipment ac-
cording to these instructions. Taking into account
the working conditions and the work being per-
formed.
The use of power tools other than those intended for
the tool itself can lead to dangerous situations.
5) Service
a. Only let qualied service personnel repair your tool
and always use original replacement parts. This gu-
arantees that the power tool remains safe to use.
Warning! This electric tool generates an electro-
magnetic eld during operation. This eld can impair
active or passive medical implants under certain
conditions. In order to prevent the risk of serious or
deadly injuries, we recommend that persons with
medical implants consult with their physician and the
manufacturer of the medical implant prior to operat-
ing the electric tool.
Additional safety rules for the belt and disc
sanding machine
Warning: Do not use your machine until it is completely
assembled and installed according to the instructions.
• If you are not familiar with the operation of the
sanding machine, ask the head of the department,
your teacher, or any other qualied person.
• Attention: This machine has only been designed
for sanding wood or similar materials. The sand-
ing of other materials can cause re, injuries, or
damage the product.
• Always wear safety goggles.
• This machine may only be operated indoors.
• Important: Mount and use the machine on a hori-
zontal surface. A non-horizontal surface can dam-
age the motor.
• If the machine tends to tilt or walk (especially when
sanding long and heavy panels), it must be fas-
tened to a solid surface of sufcient carrying force.
• Make sure the sanding belt runs in the correct di-
rection – see arrows at the back of the belt.
• Make sure the sanding belt is running correctly so
that it cannot come off the drive pulleys.
• Make sure the sanding belt is not twisted or loose.
• Firmly hold the workpiece when sanding.
• Always use the fence when using the sanding ma-
chine in horizontal position.
• Always hold the workpiece rmly to the table when
using the sanding disc.
• Always hold the workpiece to the side of the sand-
ing disc running downwards, in order to maintain
the workpiece pressed to the table. By using the
upward-running side of the sanding disc, the work-
piece could be ejected and cause injury to persons.
• Always keep a minimum distance of about 1.5 mm
or less between the table or fence and the sand-
ing belt or disc.
• Do not wear gloves. Do not hold the workpiece
with a cloth during sanding.
• Use sanding belt or disc of the correct grit corre-
sponding with the wood.
• Never sand workpieces too small to be held safely.
• Avoid awkward hand positions where a sudden slip
could cause your hand to touch the sanding belt or disc.
• When sanding a large piece of material, provide
an additional support at table height.
• Never sand an unsupported workpiece. Secure the
workpiece with the table or the fence. Exceptions
are the sanding of curved workpieces on the out-
side of the sanding disc.
• Always clear the table, fence or sanding belt of scraps
or other objects, before turning the machine on.
• Do not perform any layout assembly or set-up work
on the table while the sanding machine is in op-
eration.
• Switch the machine off and pull the power plug from
the socket when tting or removing accessories.
• Never leave the working area of the sanding ma-
chine while the tool is running, or as long as it has
not come to an absolute standstill.
6. Remaining hazards
The machine has been built using modern technol-
ogy and in accordance with recognized safety rules.
Some hazards, however, may still remain.
• The grinding wheel poses a danger of injury to
ngers and hands by improper feeding or place-
ment of tools.
• Danger of injury from thrown tools due to improper
holding or feeding.
• The use of incorrect or damaged mains cables can
lead to electrical injuries.
• Although having regarded all considerable rules
there may still remain not obvious remaining hazrds.
• Minimize remaining hazards by following the in-
structions in ”Safety Rules”, ”Use only as author-
ized” and in the entire operating manual.
7. Technical data
Technical Data
Dimensions
L x W x H mm
460/360/280
ø Disc mm 150
RPM Disc 2850
Belt dimensions mm 915x100
Belt Speed m/s 7,3
Belt Tilt 0° – 90°
Table Size mm 225x160
Table Tilt 0°-45°
Weight kg 16,5
Drive
Motor V~/Hz 230-240/50
Power W 370
Subject to technical changes!
