www.scheppach.com
30
|
GB
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
m WARNING!
The product and the packaging material are not
children‘s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
9. Layout
m Warning!
Always remove the mains plug before carrying out ad-
justments on the product.
Tool required:
(Included in the scope of delivery)
- Open-ended spanner size 19 (24)
- Open-ended spanner size 24 (25)
- Allen key, 4 mm (26)
- Allen key, 5 mm (27)
(Not included in the scope of delivery)
- Open-ended spanner / socket spanner size 8
- Open-ended spanner / socket spanner size 10
- Open-ended spanner / socket spanner size 13
- Phillips screwdriver
9.1 Fastening the machine
For use, it is recommended to x the machine on a
workbench by means of the four holes.
1. The mounting surface must be pre-drilled, taking
into account the spacing of the two mounting holes
in the frame.
2. Each xing point must be tightened with screws
(not included in the scope of delivery).
3. The screws must be suciently long: Take into ac-
count the thickness of the work surface on which
the product is to be mounted.
• Residual risks can be minimised if the “Safety In-
structions” and the “Intended Use” together with the
operating manual as a whole are observed.
• Avoid accidental starting of the product: the oper-
ating button may not be pressed when inserting
the plug in a socket. Use the tool attachment that
is recommended in this operating manual. This is
how to ensure that your product provides optimum
performance.
• Keep your hands away from the working area when
the product is in operation.
7. Technical data
Dimensions L x W x H 1030 x 475 x 530 mm
Table size L x W 610 x 365 mm
Table height 315 mm
Table width extension
dimensions L x W
210 x 365 mm
Height adjustment spindle 0 - 40 mm
Reduction pieces 32 / 47 / 55 / 75 mm
Spindle speed 11,500 - 24,000 rpm
Max. cutter Ø 80 mm
Weight approx. 21 kg
Engine 230 - 240 V~ / 50 Hz
Rated input 1500 W
Subject to technical changes!
Noise and vibration
m Warning: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Information about noise level measured in accord-
ance with EN 61029
Noise data
Sound power level L
WA
106 dB
Sound pressure level L
pA
93 dB
Uncertainty K
wa/pA
3 dB
8. Unpacking
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
