Scheppach HS105 User Manual

www.scheppach.com
GB
|
29
Table of contents: Page:
1. Introduction ........................................................................................................ 30
2. Device description (Fig. 1-4) ............................................................................. 30
3. Scope of delivery ............................................................................................... 30
4. Proper use ......................................................................................................... 31
5. Safety information .............................................................................................. 31
6. Technical data .................................................................................................... 36
7. Before commissioning ....................................................................................... 37
8. Attachment and operation ................................................................................. 37
9. Operation ........................................................................................................... 38
10. Working instructions .......................................................................................... 39
11. Transport ............................................................................................................ 40
12. Maintenance ...................................................................................................... 40
13. Storage .............................................................................................................. 41
14. Electrical connection ......................................................................................... 41
15. Disposal and recycling ....................................................................................... 42
16. Troubleshooting ................................................................................................. 43

Scheppach HS105 Specifications

General

Product color	Blue, White
Built-in light	No
Country of origin	Germany
Suitable for materials	Wood
Saw blade included	Yes
Input power	2000 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Blade diameter	255 mm
Number of teeth	60
Idle speed (max)	7000 RPM
Bevel capacity (max)	45 °
Cutting depth (45º)	50 mm
Cutting depth (90º)	80 mm

Weight and Dimensions

Depth	760 mm
Width	690 mm
Height	380 mm
Weight	30500 g
