www.scheppach.com
GB
|
23
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
m WARNING!
The device and the packaging material are not
children’s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
9. Before commissioning
m ATTENTION!
Check before starting the engine:
• Check fuel level, top up if necessary
- the tank should be at least half-full
• Ensure the device has sucient ventilation
• Make sure that the ignition cable is attached to the
spark plug
• Disconnect any connected electrical devices from
the power generator
• The condition of the air lter,
• The condition of the fuel lines,
• The rm seating of the external screw connections,
m Attention! Fill the oil before rst use.
Before each use, check the oil level with the engine
switched o and on a level surface. Use the highest
quality four-stroke oil or an HD oil with the same level
of quality. SAE 10W-30 is recommended for general
use at all temperatures.
Check the oil level (Fig. 3, 4)
• Place the generator on a level, even surface
• Open the engine cover (19) by loosening the Phillips
screw (a).
• Unscrew the oil dipstick (21).
• Fill the tank with engine oil using the funnel (15).
Note the max. lling capacity of 250 ml. Carefully ll
the oil up to the lower edge of the ller neck.
• Wipe the oil dipstick (21) with a clean, lint-free cloth.
• Re-insert the oil dipstick (21) and check the oil level
without screwing the dipstick tight again.
• The oil level must be within the middle mark on the
oil dipstick.
• If the oil level is too low, add some oil.
• Then screw the oil dipstick (21) in again.
Fill with fuel
• In order to refuel the device, open the tank cover (2)
by turning it anti-clockwise.
Drive motor type
4-stroke 1 cylinder
air-cooled
Displacement 53,5 cm
3
Max. power (engine) 1.5 kW / 2 HP
Fuel
Unleaded petrol (min. 98
octane)
Tank contents 4 l
Engine oil type 10W30 / 15W40
Oil volume (approx.) 250 ml
Consumption at full
load
1,05 l/h
Max. temperature. 40
°
C
Max. altitude (above
mean sea level)
1000 m
Spark plug A7RTC
Performance class G1
Weight 13 kg
Technical changes reserved!
Noise and vibration
m Warning: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Noise data
Sound power level L
WA
92.9 dB(A)
Sound pressure level L
pA
72.6 dB(A)
Uncertainty K
wa/pA
2 dB(A)
8. Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating instructions before using for the rst time.
• With accessories as well as wearing parts and
replacement parts use only original parts. Re-
placement parts can be obtained from your dealer.
