Scheppach SG7300 - Technical Data; Unpacking

www.scheppach.com
32
|
GB
Rated current I
n
(12 V DC) 8.3 A
Rated current I
n
(230 V) 21.7 A
Rated current I
n
(400 V 3
~
) 7.3 A
Frequency F
n
50 Hz
Performance class G2
Active power factor φ Single phase / Three
phase: 1 / 0.8
Quality class B
Drive motor type 4-stroke, 1 cylinder,
air-cooled
Displacement 420 cm
3
Max. power (engine) 9,3 kW / 12,6 PS
Fuel Super E10 petrol
Tank contents 25 l
Engine oil type 10W30
Oil volume (approx.) 110 ml
Weight 84 kg
Temperature T
max
40
°
C
Spark plug type F6RTC / F7RTC
Max. installation altitude
(above sea level)
1000 m
Battery type Lead acid
Battery capacity 17 Ah
Subject to technical changes!
Operating mode S1 (continuous operation)
The power generator can be operated continuously
with the specied power.
Operating mode S2 (short-term operation)
The power generator may only be operated at maxi-
mum power for a brief time.
Information about the noise level measured in accord-
ance with applicable standards (EN ISO 3744:1995,
ISO 8528-10:1998):
Sound pressure L
pA
76,8 dB
Sound power level L
wA
96,2 dB
Measurement uncertainty K
pA
1,1 dB
Wear hearing protection.
Excessive noise can result in a loss of hearing.
7. Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Always charge the battery in a closed room with
good ventilation, dry and protected against the
weather.
• Do not short-circuit battery connections.
• Deformed or defective (leaking) batteries must not
be used and must be replaced and disposed of in an
environmentally friendly manner. Observe the coun-
tryspecic regulations.
• If the batteries are defective, liquid may leak out.
Avoid contact! In case of accidental contact, rinse
with water. If the liquid gets into your eyes, seek ad-
ditional medical attention. Leaking battery uid can
cause skin irritation, burns and chemical burns.
• Regularly visually inspect the connection cables on
the battery for damage. Have damaged cables re-
placed by a specialist.
• Never bypass the fuses. Never use a fuse with a rat-
ing other than the prescribed rating (amperes).
Residual risks
The device is state-of-the-art and has been built in ac-
cordance with the recognised technical safety rules.
However, individual residual risks can arise during op-
eration.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety In-
structions” and the “Intended Use” together with the
operating manual as a whole are observed.
• Avoid accidental start-ups of the power generator.
• Use the device in the way that is recommended in
this operating manual. This is how to ensure that
your power generator provides optimum perfor-
mance.
6. Technical data
Protection category IP23M
Continuous output power P
n
(COP) (230 V) (S1)
3,5 kW
Continuous output power P
n
(COP) (400 V 3~) (S1)
5.0 kW
Max. power P
max
(230 V)
(S2 5min)
3,68 kW
Max. power P
max
(400 V 3
~
)
(S2 5min)
5.5 kW
Rated voltage U
n
230 V
~
/ 400 V 3
~
