2 Introduction
2.2 Configurations
Page 24
Art. no.: 2.511335 Rev. a
CARDIOVIT CS-104
2.2 Configurations
The CS-104 is available in the following configurations:
2.2.1 CARDIOVIT CS-104
• Installed on a PC.
– Resting ECG (including Resting rhythm)
– MS-12 blue or MS-12 USB or FT-1 streamer
– Network connection with SCHILLER Server
2.2.2 CARDIOVIT CS-104 System
• Installed on a trolley with PC and 21’ monitor (see previous page)
– Resting ECG (including Resting
rhythm)
– Exercise ECG (with stage printout on externa
l printer (option)
– MS-12 blue or MS-12 USB or FT-1 streamer
– Network connection with SCHILLER Server
2.2.3 CARDIOVIT CS-104 Spiro
• Installed on a PC and not upgradable with any options
– Spirometry software for FVC, SVC, and MVV measurment
– SpiroScout SP plus sensor.
– Network connection with SCHILLER Server
2.3 Options and Features
• The features and options available with the CS-104 are as follows:
Network Std Std
Std
Resting ECG Recorder Std Std -
Analyse All Recording Types (SEMA) Std Std
-
External Recorder Std Std -
Visual Comparison (Serial) Std Std
-
Exercise ECG Opt Std -
Spirometry Opt Opt
Std
ETM Interpretation Opt Opt -
Vector ECG Calculation Opt Opt
-
HL7AEcg Export Opt Opt -
Arrhythmia Detection Opt Opt
-
Advanced Interpretation Editor Opt Opt -
FT-1 Streaming Opt Opt
-
Worklist Opt Opt Opt
Option CS-104 CS-104 System CS-104 Spiro

Schiller CARDIOVIT CS-104 Specifications

General

ECG Channels	12-channel
Recording Speed	5, 10, 25, 50 mm/s
Memory	Internal memory for up to 350 ECGs
Type	Resting ECG Device
Display	Color touchscreen
Input Impedance	>100 MOhm
Power Supply	AC adapter or rechargeable battery
Interpretation	SCHILLER ECG Interpretation
Connectivity	USB, LAN
Data Transmission	XML
Battery Life	Up to 4 hours
