Schiller CARDIOVIT CS-104 User Manual

3 Software Overview
3.6 Connection with the Server (if Networked)
Page 38
Art. no.: 2.511335 Rev. a
CARDIOVIT CS-104
3.6.1 Offline
When connection to the server is lost for whatever reason, a cross appears . and
on login offline mode is indicated:
Station offline
User name*:
Password:
Login Exit
Click here to check SEMA Server path (see
para. 11.4, Connectivity, page 123)
In offline mode:
• Any opened recordings or patient da
ta can continue to be edited and viewed but
any edits cannot be saved until the server is reconnected (the save option is
greyed).
• New patients can be defined and recordings can continue to be made and saved.
These are stored locally, and will be synchronised with the server when reconnect-
ed.

Schiller CARDIOVIT CS-104 Specifications

General

ECG Channels	12-channel
Recording Speed	5, 10, 25, 50 mm/s
Memory	Internal memory for up to 350 ECGs
Type	Resting ECG Device
Display	Color touchscreen
Input Impedance	>100 MOhm
Power Supply	AC adapter or rechargeable battery
Interpretation	SCHILLER ECG Interpretation
Connectivity	USB, LAN
Data Transmission	XML
Battery Life	Up to 4 hours
