Schiller Mantis 7566A - Parts List

23
Schiller Grounds Care, Inc. P/N 802-0006
Key Qty. Part No. Description 1 1 940-0002** Trigger Handle Assembly, 4 Cycle Engine, Right 2 1 940-0002** Handle Assembly, Left 6 1 940-0002** Lower Handle W/Plug, Right 7 1 940-0002** Lower Handle W/Plug, Left 8 1 940-0002** Handle Brace 9 1 940-0002** Label, Handle Brace 10 1 430023 Front Carry Handle, Right 11 1 430022 Front Carry Handle, Left 12 1 910502 10-32 X 3/4” Flange Bolt 13 2 940-0002** Throttle Clip 14 2 940-0002** Foam Grip 15 1 940-0002** Rear Carry Handle W/Grip 16 2 940-0002** Bolt 1/4-20 X 3.25” 18 1 940-0002** M6 Jam Nut 20 1 430209 Fender Guard with Labels 21 1 400916 Engine Assembly-35cc Honda® 22 1 468 Drive Shaft 23 1 400301 Worm Gear Housing 24 1 436 Gasket 25 1 437A Gear Housing Cover 26 4 651 #8 Self Tapping Screw 27 1 423 Roller Bearing 28 2 425 Worm Bearing Race 29 1 424SH Worm Thrust Bearing 30 1 422 Worm Shaft 31 1 426 Worm Disk 32 1 428 Retaining Ring 33 1 429 Worm Gear 34 1 431 Tine Shaft 35 2 430 Worm Gear Thrust Washer 36 2 432 Worm Gear Bearing
Key Qty. Part No. Description 37 2 434 Bearing 38 2 435SH Bearing Seal Retainer 39 1 438RA Tine Assembly, Outer Right 40 1 438LA Tine Assembly, Outer Left 41 2 418-1 Tine Retaining Pin 42 2 430039 Carriage Bolt 1/4-20 X 2.25” 43 1 400307 Clutch Hub Adapter 44 1 430226 Triangle Warning Label (4 Cycle Engine) 45 1 458SH Roller Bearing 46 1 430058 Mantis Logo Label 47 2 395 Acorn Nut 48 6 940-0002** 1/4-20 Two-Way Lock Nut 49 4 940-0002** 1/4-20 X 1.125 Hex Head Cap Screw 50 2 400516 Bolt 1/4-20x1/2” Long 51 1 430057 Warning Label 52 1 400302 Transmission Assembly* 53 2 940-0002** Knob, Two Prongs, Female 54 1 430043 Ground Wire Jumper, 4 Cycle Engine 56 1 400132SH Bearing 57 1 400308 Clutch Drum 58 4 400529 M6x33mm Flange Bolt 59 1 410158 Kickstand, Stand Assembly 60 1 430037 Kickstand, Bracket And Hardware 61 1 400524 Retaining Ring 62 1 400310 Throttle Stop, Honda® 34cc 64 1 400313 Dust Cap for Grease Fitting 65 1 400300 Grease Fitting 66 1 400330 Tine Assembly, Inner Right 67 1 400329 Tine Assembly, Inner Left 69 2 400635 Label XP Tine Warning 70 1 400310 Throttle Stop
* Includes Key #22 ** Included with service kit 940-0002
