Schiller Grounds Care, Inc. P/N 802-0006
DESCRIPTION OF PRODUCT
Please read this entire manual before installation and use. Schiller Grounds Care reserves the right to change, alter
or improve the product and this document at any time without prior notice. Due to continuous product improvements,
product images may not be exact. Some assembly may be required.
Read and keep this manual for future reference. This manual contains important information regarding safety, assembly, operation,
and maintenance. The owner must be certain that all the product information is included with the unit. This information includes the
manual, the replacement parts, and the warranties. This information must be included to make sure state laws and other laws are
followed. All persons who rent/loan this unit must have access to and understand this information. This manual should remain with
the product even if it is resold.
NOTICE
THIS IS A MOTORIZED ROTARY TILLER THAT WORKS THE SOIL BY MEANS OF ROTATING TINES. IT IS PEDESTRIAN-
CONTROLLED, BUT NOT SELF-PROPELLED, WITH A GASOLINE-FUELED INTERNAL COMBUSTION ENGINE TO
POWER THE TINES. IT SHALL NOT BE USED FOR ANY OTHER PURPOSE.
PURPOSE
TECHNICAL DATA
EMISSIONS
Refer to the engine owners' operating manual for further details related to this Honda statement: Your new Honda engine
complies with both the U.S. EPA and State of California emission regulations. American Honda provides the same emission
warranty coverage for Honda Power Equipment engines sold in all 50 states. In all areas of the United States, your Honda Power
Equipment engine is designed, built, and equipped to meet the U.S. EPA and California Air Resources Board emission standard for
spark ignited engines.
SPARK ARRESTOR
This unit is factory equipped with a spark arrestor. Some federal, state, and local authorities require, by law, that certain
internal combustion engines operated on forest brush and/or grass-covered areas be equipped with a spark arrestor, maintained
in effective working order, or the engine be constructed, equipped and maintained for the prevention of re. Check for regulations
pertaining to these requirements. Failure to follow these requirements could subject you to liability or a ne. If it requires
replacement, contact your local service dealer to install the appropriate mufer assembly.
PRODUCT COMPLIANCE
Product 7566A (XP model)
Engine 4-cycle Honda
Displacement (cc) 35
Fuel Capacity (qt. / L) 0.67 / 0.63 No mixing of gas and oil required
Tilling Width, in (cm) 16 (40.6)
Tilling Depth, in (cm) 10 (25.4)
Max Tine Speed 240 rpm
Dimensions L x W x H, in (cm) 54 x 18 x 20 (138 x 46 x 51)
Dry Weight, lbs (kg) 34 (16)
Starting/Operation Recoil, Variable speed throttle
Warranty* 2-Year Consumer / 2-Year Commercial / Rental
