Governor Rope Coupling [17968; 18.08.2006]
Governor Rope
Checks
Wire Breaks [18376; 15.09.2006]
1 Washer
2 Cotter pin
3 Clevis pin
4 Governor lever
5 Spring wire
4
5
1
2
3
1 Wire rope
2Core
3Strand
4Wire
No Step
1
Check the condition of the governor rope. The rope must be replaced if:
– 6 or more broken wires are found in one lay
– 3 or more broken wires are found in one strand of one lay of rope (X).
– The rope is showing signs of red dust or rust, or is damaged or disfigured in
any way
– The diameter of the rope has reduced by more than the rope
manufacturers recommended limit (usually 5 ... 10 %).
X
1
3
4
2
