5.3 Basic Characteristics of Traction Media and Governor Rope
Governor Rope
– Supplier instruction
– According ISO 4344
– Right hand lay rope, ordinary lay
– Single tensile grade of wire 1770 (N/mm2) acc. ISO 4101
– Preformed
– Galvanized drawn grade B acc. to ISO 2232
– Lubrication: Stand 0.2 ... 0.4 % of rope weight, Core < 10 % of core weight
– Post lubrication: non
Characteristic Values / Comments
Width of STM 30 mm
V-shaped STM 90 °
Min. Breaking force 42.0 KN
Min. Tensile grade of wires 2500 N/mm
2
12 Fine-strand steel cord, high flexible, left and
right lay with galvanized wires
19 + 8 x 7, ∅ 1’73 mm
Cover-Material PU or EPDM
Non-combustible (non-toxic gaz) cover
UL 94
Determination toxicity UL 94
In flammability UL 94 (self extinguished)
Smoke UL 94
Self-extinguishing
Temperature application range 0 ° ... 60 °C
Relative humidity < 90 °
Nominal
Rope Dia.
(mm)
Tol. Type Weight
(kg/m)
Rope
Construction
Min.
Breaking
Force FZM
(kN)
Used for
GQ (kg)
6.0 + 2/+ 6 % - 0.13 Seal 6 x 19
fibre core
chemical PP
> 21.0 320 ... 1000
