Schindler 6300 - Error Codes

Schindler 3100/3300/6300 J 43402603 / 01 99/269
Copyright © 2017 INVENTIO AG
4.9.5 Error Codes
The following list of error codes cover all control and software variants.
Some errors are for Research and Development only and therefore not relevant.
Error Messages and Recovery Procedures (related to Menu 50)
Some recoverable errors are reclassified as "fatal error" if they occur repeatedly. This is
indicated in the following tables as shown in the example below.
Example: "
3x = F" means that three occurrences of the respective recoverable error
within one hour make it a fatal error.
Legend:
– C1, C2, C3, ...: Cause 1, 2, 3, ... of the error
–
A1, A2, A3, ...: Action 1, 2, 3, ... to solve the error
– Any error displayed during the calibration belongs to error group 11. (Example: er 9 =
Error 1109)
– Errors (E0–E9) displayed during the LOP configuration are described in chapter
about the LOP configuration.
Code General Message
0001
ELEVATOR FATAL ERROR
The elevator is permanently blocked and not operable. Note that this message
typically follows another error.
C1:Different causes
A1:Check elevator message log for previous reported messages in order
to identify the root cause of the problem.
0002
ELEVATOR SAFETY CHAIN
The safety circuit has opened unexpected or hasn't closed as expected.
C1:The safety circuit has opened unexpected (for example, while the car
was moving)
A1:Check safety circuit for opened contacts.Check 110 V fuse on
SMICHMI/SMICFC board.
C2:Safety chain has not closed when expected. When all doors are
closed, the safety circuit is expected to be closed too.
A2:Check safety circuit contacts at door.Check door parameter 'delay
time between door closed and closed safety circuit' (CF03 PA13).
C3:Safety chain is not powered due to UCM (unintended car movement)
actuation.
A3:Check UCM recovery procedures (for example, remove persistent
fatal error).
0003
ELEVATOR OVERLOAD MODE
C1:Too high load in the car
A1:Decrease the load in the car
C2:The car load measuring signal is faulty
A2:Check general wiring to the car load measuring device.Redo
calibration if signal is present but invalid.
0005 ELEVATOR POWER FAIL MODE
0008 ELEVATOR JRVC MODE *)
