Schindler 3100/3300/6300 J 43402603 / 01 205/269
Copyright © 2017 INVENTIO AG
Door Drive (shown: C2, single clutch, CDL) [45310310_001; 22.04.2015]
[41353545_014; 03.07.2014]
1HMI keypad
2 Power switch (JHT)
1Clutch sword
2 KTC contact arm
3 KTC contact housing
4 KTC contact bridge
5 Clutch release lever
6Clutch cam
7 KET-S2 contact bridge
8 Lock hook
9Lock latch
10 Carriers
11 Stopper rubber
12
4
3
2
1
11
10
7
9
8
56
