Schindler 6300 - Page 213

Schindler 3100/3300/6300 J 43402603 / 01 213/269
Copyright © 2017 INVENTIO AG
Check Lock
Engagement on First
Contact
[41353545_025; 03.07.2014]
No Step
1
Press the carriers into the closed stopper rubber.
2 Move the KTC contact bridge (1) into the housing (2) until a first contact is
established.
3 Check the CDL engagement is ≥ 7 mm.
1 Contact bridge
2 Contact housing
1
2
