Schindler 3100/3300/6300 J 43402603 / 01 256/269
Copyright © 2017 INVENTIO AG
Lubricators
Guide Shoe Check [11459; 07.03.2005]
No Step
1
Check the lubricators (7) for any damages and for leaking oil.
2 Check that the lubricator felts (8) are moistened with oil and that there is an oil
film on the guide rails (3).
3 Open the oil tank and carefully add oil.
4 Close the oil tank afterwards and clean up any spilled oil.
5 Check that the dimension is ≥ 14 mm. If not, the guide shoe liner must be
replaced.
