Power Fail
Notification
The following procedure describes a power fail notification. Reception of the call, steps
to be made for acknowledgement of the call as requested by the EN 81-28.
Please take note of the fact the telephone codes need to be used as pointed out.
1)
If the alarm device answers with #99# then the TA device did not get the DTMF
commands right. Try again to send the command.
Rescue Service Handling from → to Remote Alarm Device
Establish
Connection
← ring - The TA device dials the
rescue monitoring
number
- the rescue service
answers the
incoming call
Verify
Installation ID
- ask the Installation
ID with
#10# →
←
#12xxxxxxxxxxxx#
- sends Installation ID
(x=0 to 999999999999)
Verify Unit ID
and Status of
Battery
- ask the Unit ID
with
#13# →
←
#14abcd# - sends Unit ID
(a=1 to 8)
- sends notify
b = 0: notification call
c = 0: all power ok
c = 1: mains power nok
c = 2: ind/batt nok
c = 3: all power nok
c = 4: battery low in
power fail
c = 5: battery defect
Acknowledge - acknowledge
notification call
#221# →
←
#00#
Close
Connection
- send the hang up
signal
#24# →
- the rescue service
hangs up
←
#00#
1)
- sends ok
TA device hangs up the
phone line
