Set the
Configurations
Mode
Change Parameter
S
Submenu: Door side
– Only visible in case of independent door operation (ZZ2 or ZZ3
on the SIM card)
– Applies to CF40 and CF41 only
–“S 1” → Door side 1, “S 2” → Door side 2
LE Submenu: Level, applies to CF00 only
VL Value
Menu Element Description
Pos. Step Display
1
Check the HMI for the current car position (for example car at
floor 5).
_ _ _ _ 0 5
2 Press the OK button to enter the main menu level. 1 0 _ _ _ _
3 Press the UP or DOWN button as required to navigate to the
desired main menu (for example main menu 40).
4 0 _ _ _ _
4 Press the OK button to confirm the main menu selection. 4 0 _ _ _ 0
5 Press the UP or DOWN button as required to change the
value from “0” to “1” (applies to main menu 40 only).
4 0 _ _ _ 1
6 Press the OK button to activate the configuration mode
(applies to main menu 40 only).
This will:
 Display the configuration group CF01.
 Send the car to the configuration floor, where it remains
stationary with the doors open. The system is then ready
for configuration.
C F _ _ 0 1
Pos. Description and Remarks
1
Make sure that the system is ready for configuration.
Enter Configuration Mode as described above if applicable.
C F _ _ 0 1
2 Press the UP or DOWN button as required to navigate to the
desired configuration group (for example Door Timing CF03).
C F _ _ 0 3
3 Press the OK button to confirm the configuration group
selection.
This will display the first parameter of the parameter menu.
P A _ _ 0 1
4 Press the UP or DOWN button as required to navigate to the
desired parameter (for example Start Delay PA08).
P A _ _ 0 8
5 Press the OK button to confirm the parameter selection.
This will display the current value xyz of the selected
parameter.
V L _ x y z
6 Press the OK button to enter Edit Mode (Change Mode).
The first digit from the left will start blinking to indicate that it
can be changed.
V L _ x y z
7  Either press the UP or DOWN button as required to
change the digit to the desired value (for example x to u)
 Or go directly to the next step.
V L _ u y z
