7 Place battery in holder and tuck wires.
Tuck battery and wires behind the tabs.
Tabs
8 Install battery cover.
Angle the cover up to install, then screw the cover in.
9 Install strike onto door jamb.
Actual Size
10 If needed, switch levers.
c
If your lever looks like this,
then no change is necessary.
If your lever does not look like
this, switch the levers by
following the steps below.
OR
Insert the pin wrench
into the hole in the
lever. Push in and hold.
Pull the lever off. Repeat steps a and b to remove the
lever from the other side of the door.
Switch the levers.
Push each lever back
into place.
Correct
Incorrect
a
b
d
To Next Page
