Operating Instructions
Dear customer
You have certainly made a good choice. The SCHLEUNIGER 207 is the most advanced coaxial cable stripper available. The
SCHLEUNIGER 207 can precisely strip coaxial cables with up to 3 stages in one operation . But that is not all, the SCHLEU-
NIGER 207 can store all the stripping values for a total of 39 different coaxial cables. Once the machine is programmed , the
time required for changeover when stripping different cables is under 3 seconds. Just switch to the desired cable no ., and the
SCHLEUNIGER 207 works exactly according to the values stored. In these operational instructions- also available in German
and French- you will find exact instructions for use. Before putting the machine into operation, please read these instructions
carefully, so that you get to know your SCHLEUNIGER 207 inside and out- it will reward you for this reliability. Should you
have any questions, we are of course readily available with guidance and help at any time.
The advantages
of the SCHLEUNIGER 207
The SCHLEUNIGER 207 can strip most of the
coaxial cables available, up to a diameter of 7 mm
(.275 in.). The stripping head of the SCHLEUNI-
GER 207 is designed with all of the technical re -
finements to guarantee the best possible opera-
tion . The free open i ng ofthe stripping head allows
the conductors to be fed directly from above. As
soon as the cable touches the sensor, the ma-
chine cycle begins . The gripper jaws centralize
and hold the cable , the programmed stripping
being carried out fully automatically within sec-
onds.
The SCHLEUNIGER 207 can store all of the
stripping values for a total of 39 different cables.
The stripping values stored can be called up at
random and remain stored for over 2 years without
electricity.
The stripping diameters can be set to within . 01
mm (.001 in.) on the SCHLEUNIGER 207. Thus ,
optimal stripping quality is guaranteed and dam-
age to the conductors is eliminated. Co r rections
due to cable tolerances can be carried out with the
thumbwheel switches.
The stripping blades, made of carbide, make flaw-
less stripping of all typical insulating materials with
low wear on the blades . For extreme use, blades
of carbide, titanium coated can be used .
The SCHLEUNIGER 207 works purely electrically
and uses only 80 VA.
The few parts subject to wear on the machine, es-
pecially the stripping blades and the cable central-
izers , can be replaced quickly and easily . The
SCHLEUNIGER 207 is light, weighing only 6 kg
(13.21bs .) and can be easily transported.
Maintenance and cleaning tasks are few. The
SCHLEUNIGER 207 is easily accessible for main-
tenance work .
The SCHLEUNIGER 207 works extremely quietly
and fulfills all the safety directives required .
The electronic controls guarantee flawless func-
tioning of the machine for years without problems.
Page 3
Yours truly,
Dr. Kurt Schleuniger
Service arrangements
Please read the "Certificate of Guarantee" which
was shipped with your machine. This certificate
will explain your warranty completely. We cannot
undertake any liability for damage which comes
about through abuse. In your best interest , please
do not perform any alterations or modifications to
the machine .
The SCHLEUNIGER service department is avail-
able throughout the week. Call us or your nearest
representative when a problem arises which you
cannot solve yourself. Describe precisely what is
not functioning properly on your SCHLEUNIGER
207 . No r mally , our experts can solve the problem
with instructions on the telephone. Thus, possible
downtime can be kept to an absolute minimum .
