SAFETY INSTRUCTIONS
30.30.01.00173/04 www.schmalz.com EN | 9
1.5 Intended use
The vacuum tube lifter JUMBO is used to lift and transport objects. The loads to be lifted have to be
rigid to ensure they are not destroyed during lifting.
The permissible upper load limits are defined in section 3 (Technical Data) and must not be exceeded.
For details of the maximum permissible load, also refer to the type plate of the respective lifting device!
The vacuum tube lifter JUMBO must not be converted or modified independently. It should only be
operated in the original condition as delivered.
Using the vacuum tube lifter JUMBO for products that are not named in the order confirmation will be
considered improper or unintended use; if products that are not specified in more detail are used,
these must have the same physical properties as the products named in the order confirmation.
Avoid carrying loads at an angle!
Always pick up loads above the center of gravity
The vacuum tube lifter Jumbo is state of the art and operationally reliable provided
full compliance with these instructions is assured. Incorrect handling of the vacuum
tube lifter Jumbo could cause dangers to arise.
Unauthorized modifications or changes to the vacuum tube lifter JUMBO
will compromise the integrity and function of the gripper.
There is a risk that the load or gripper may fall, crushing body parts or
fatally injuring people in the vicinity.
► Do not make any on-site modifications to the system!
Danger of death from falling if used as a means of transport for
humans or animals, or as a climbing aid
This can result in broken bones, serious injury or even death.
Use of the vacuum tube lifter as a climbing aid or to transport humans or
animals is prohibited!
