Operating Instructions
VACUMASTER
Chapter 8 / 9
Type plate /
Spare and wearing parts
J. Schmalz GmbH
Aacher Straße 29
D - 72293 Glatten
Tel +49 +7443 / 2403 - 0
Fax +49 +7443 / 2403 - 259
http://www.schmalz.de
e-mail: schmalz@schmalz.de
30.30.01.00185 Status 03.2013 / Index 00 Page 26 / 28
8 Notes on the type
plate
The type plate contains important data on the device.
The type plate is attached to the exterior of the device.
The type plate contains the following data:
Device type
Device number
Order number
Year of construction
Maximum load bearing capacity
Weight
The device type, device number and year of construction are important information
for identifying the device. They must be specified when ordering replacement
parts, making warranty claims or other queries on the device.
The maximum load bearing capacity indicates the maximum load for which the
device is designed. This maximum load must not be exceeded.
The weight entered on the type plate must be taken into account when using the
device on a hoist (e.g. crane, chain hoist, …).
Additional electrical connection data specific to the device attached to the lifting
device absolutely must be observed!
9 Warranty, spare and wearing parts
This device is guaranteed in accordance with our general terms of trade and
business. This also applies to spare parts, provided they are original parts
supplied by us.
We accept no liability for damage caused by the use of spare parts or accessories
made by other manufacturers.
All wearing parts are not covered by the warranty.
The following list contains the primary spare and wearing parts.
Legend: - Spare part = S
- Wearing part = W
- Wearing part assembly, contains wearing parts = WA
