2 Technical specifications
Generating a vacuum with an electrical pump
EVE pump type
4 D
8 D
16 D
25 D
40 D
Power consumption [kW]
0.18
0.35
0.55
0.9
1.25
Suction capacity [m³/h]
4
8
16
25
40
Fuse rating (recommended) [A]
10
16
Temperature range
+0°C to +40°C
Noise (DIN 45 635) [dB(A)]
61
61
61
65
68
See the pump operating instructions for the remaining specifications of the pump.
Vacuum generation with multi-stage ejector
Type of ejector
SEM 100 - SDA
Compressed air connection
G ¼“
Vacuum connection
G 1“
Max. suction rate [m³/h]
58,6
Noise [dB(A)] free
81
Noise [dB(A)] with suction
60
See the ejector operating instructions for the further technical information about the ejector.
Max. permitted loads
VM 125*
VM 250*
VM 500
VM 750
VM 75-
90°/180°
VM 125-
90°/180°
VM 250-
90°/180°
VM 500-
90°
125kg
250kg
500kg
750kg
75kg
125kg
250kg
500kg
The permitted loads refer to a vacuum of -0.6 bar, all suction plates are covered by the workpiece.
For rotating devices, a friction factor of µ=0.5 between the suction plate and workpiece is assumed (check the
actual friction factor if necessary !).
*for the pneumatic lifting devices VM 125 and VM 250, the permitted loads refer to a vacuum of -0.2 bar.
