Schmalz VSi Series User Manual

PRODUCT DESCRIPTION
10 | EN www.schmalz.com 30.30.01.00956/01
2.3 VSi design (without display)
Item
Description
1
Fluid connection
2
Switching point 1 display, ORANGE or operating voltage display, GREEN
3
Position of the NFC antenna
4
Electrical connection M12-4 or M8-4
2.4 VSi design … D (with display)
Item
Description
1
Fluid connection
2
Switching point 1 display, ORANGE or operating voltage display, GREEN
3
Position of the NFC antenna behind the display
4
Electrical connection M12-4 or M8-4
5
MODE button
6
Display
7
SET button
8
Switching point 2 display, ORANGE
1 3 4
2
1 5 82 6 3 7 4
