Schmalz VSi Series User Manual

TECHNICAL DATA
30.30.01.00956/01 www.schmalz.com EN | 11
3 Technical Data
3.1 General data
Measuring medium
Non-aggressive gases; dry, oil-free air
Operating pressure range
V -1to 0 bar
P10 0 to 10 bar
VP8 -1 to 8 bar
Overpressure resistance
V 8 bar
P10 15 bar
VP8 12 bar
Accuracy
± 3% FS
1)
Resolution
V 1 mbar
P10 11 mbar
VP8 Vacuum 2 mbar/pressure 11 mbar
Degree of protection
IP 65 (M8/M12 plugged in)
Working temperature
0 to 50 °C
Storage temperature
-10 to 60 °C
Permitted humidity
10 to 90% RH (free from condensation)
Materials used
Housing PA12
Fluid connection Stainless steel
Seals NBR
Weight
VSi 12 g
VSi … D 16 g
1)
The accuracy applies to the entire measuring and temperature range.
3.2 Electrical data
Supply voltage
DC 10to 30 V (PELV)
2)
Power consumption (where U = 24 V)
VSi < 35 mA
VSi … D < 35 mA
Current load rating per output
100 mA
Polarity reversal protection
Yes, all connections
Overload/short circuit OUT1/OUT2
Automatic switch-off of both outputs
NFC
NFC Forum Tag type 4
IO link
IO link 1.1 Class A
Baud rate COM2 (38.4 kBits/s)
Minimum cycle time 2.3 ms
(also see separate data dictionary)
Display (only VSi…D)
3-digit, 7-segment display with decimal point
Display resolution (only VSi…D)
Vacuum 1 mbar
Pressure 10 mbar
2) The power supply must correspond to the regulations in accordance with EN60204 (protected extra-low voltage).
