6.3 Extended functions (EF)
An extended configuration menu is available for applications with special requirements. The menu
item order is as follows:
Menu item
Example
Description
AF
AF menu title in basic menu
Ou1
H.no
Switching function, switching output 1:
H.no/H.nc: Hysteresis function, normally open/normally closed
F.no/ F.nc: Window function, normally open/normally closed
C.no/C.nc: Condition monitoring function, normally open/normally
closed
d.no/ d.nc: Diagnosis function, normally open/normally closed
Ou2
H.no
Switching function, switching output 2: (see Ou1)
dS1
0
Switch-on delay for switching point 1 in ms
dr1
0
Switch-off delay for switching point 1 in ms
dS2
0
Switch-on delay for switching point 2 in ms
dr2
0
Switch-off delay for switching point 2 in ms
uni
bAr
Display unit:
bAr: Millibar/Bar
kPa: Kilopascal
IHg: Inch Mercury
PSI: Pound-force per square inch
Eco
off
Eco mode:
off: no eco mode
on: Eco mode with display switch-off
Lo: Eco mode with dimmed display
dIS
Std
Display alignment: Std (standard)/red (rotated)
Pin
000
Pin code for the menu
P-n
PnP
Transistor functions of both outputs: PnP/nPn
rES
No/yes
Reset to factory settings
Return to menu title
