INSTALLATION AND COMMISSIONING
30.30.01.00956/01 www.schmalz.com EN | 13
4 Installation and commissioning
4.1 Assembly
Screw-in aid (see accessories)
To install the switch on the fluid connection, screw it in with a maximum of 2.5 Nm.
The screwed-in switch can be turned back slightly to align it.
4.2 Electrical connection
Moving systems/parts throughout the production facility during set-up at
the workplace
Death or very serious injury/material damage
Do not enter the danger zone when the system is operational.
Risk of fire and explosion
Death or very serious injury
The switch must not be used in environments where there is a risk of
explosion.
The output signals can change when the power supply is switched on or
a plug connector is plugged in.
Serious personal injury and/or damage to property
The electrical connection must only be carried out by individuals who are able
to assess the impact of signal changes on the overall machine / facility /
system.
