Schmalz VSi Series User Manual

MANUAL OPERATION OF THE DISPLAY VERSION
30.30.01.00956/01 www.schmalz.com EN | 25
The counters and serial numbers are 9-digit whole numbers. These are divided into three blocks of
three numbers when indicated in the display. One of the decimal points will flash to indicate whether it
is referring to the highest, middle or lowest block. The display starts with the 3 highest numbers and
can be scrolled through using the set button. This is illustrated in the table using the Cc1 counter.
The switch's part number will also be properly distributed into number blocks for the display and can
be scrolled through using the set button. The decimal point indicates your position within the 11-digit
article number. Part number 10.06.02.00589 is used in the table as an example.
6.5 Displaying the basic settings (slide show)
By pressing the mode button in the basic status, the selected basic settings for the switch are
automatically displayed one after the other in the display.
These basic settings are:
 Switching point Sp1
 Reset point rP1
 Operating mode display (SIO or IO link)
 Supply voltage
The display cycle returns to the vacuum display after a complete cycle or can be canceled at any time
by pressing any button.
The switch is not a precise voltage meter, but the voltage displayed can still be
used as a reference value and for comparative measurements.
