INSTALLATION AND COMMISSIONING
14 | EN www.schmalz.com 30.30.01.00956/01
Noise pollution due to incorrect installation of the media connection
Hearing impairments may occur in the longer term
Pressure can cause closed devices to explode
A vacuum can cause closed devices to implode
Damage from flying or aspirated parts
Inappropriate voltage supply
Only operate the switch using power supply units with protected extra-low
voltage (PELV)
betreiben
The system must incorporate safe electrical cut-off of the power supply in
compliance with
EN60204
Do not connect or disconnect the plug connectors when voltage is applied
The electrical connection of the switch is made using a 4-pin M-12 or a 4 pin M-8 connector.
The maximum cable length is 30 m in SIO operation and 20 m in IO-link operation.
Incorrect connection on IO-Link Class B Port.
Poss. damage to the IO- Link Master or periphery
When operating the IO-Link Class A switch with an IO- Link Master with Class
B Port ensure compliant connection and isolation
