Switching distances in mm to IEC 60947-5-3 Actuator RST Actuator RST V2
Sensor RSS s
typ
12 12
s
ao
10 8
s
ar
16 16
Sensor RSS V2 s
typ
12 12
s
ao
10 10
s
ar
20 20
F
With the combination of "old sensor - new actuator (V2)" there may be limitations in availability owing to the reduced s
ao
(8
mm). This change has no affect on the performance level.
The side allows for a maximum height misalignment (X) of sensor and actuator of ± 8 mm (e.g. mounting tolerance or
due to guard door sagging). The axial misalignment (y) is max. ± 18 mm.
F
Latching versions X ± 5 mm, Y ± 3 mm.
The latching force will be reduced by misalignment.
Actuating curves
The actuating curves represent the typical switching distance of the safety sensor during the approach of the actuator
subject to the actuating direction
Transverse misalignment Height misalignment
F
Preferred actuation directions: from front or from side
4.5 Adjustment
