Termination Cable (Y-UL 2517), 8-pole
Note (length of the sensor chain) Cable length and cross-section change the voltage drop dependiing
on the output current
Note (series-wiring) Unlimited number of devices, oberserve external line fusing, max. 31
devices in case of serial diagnostic SD
Length of cable 2 m
Cable section, maximum 8 x 0.35 mm²
Wire cross-section 22 AWG
Cable type LiYY
Mechanical data - Dimensions
Length of sensor 22 mm
Width of sensor 106.3 mm
Height of sensor 25 mm
Ambient conditions
Degree of protection IP65
IP67
IP69
Ambient temperature -25_+70
Storage and transport temperature, minimum -25 °C
Storage and transport temperature, maximum +85 °C
Material temperature resistance of the cable (in motion), minimum -10 °C
Material temperature resistance of the cable (at rest), minimum -30 °C
Relative humidity, maximum 93 %
Note (Relative humidity) non-condensing
non-icing
Resistance to vibrations 10 … 55 Hz, amplitude 1 mm
Restistance to shock 30 g / 11 ms
Protection class III
Permissible installation altitude above sea level, maximum 2,000 m
Ambient conditions - Insulation values
Rated insulation voltage U
i
32 VDC
Rated impulse withstand voltage U
imp
0.8 kV
Overvoltage category III
