Assembly
36
08.00 | MPG-plus | Assembly and operating manual | en | 0389216
NOTE
For the sizes MPG-plus 16 – 20, quering the position "part
gripped" is not possible.
5.3.8 Mounting the flexible position sensor FPS
The flexible position sensor FPS consists of a control unit output
and one of the following sensors:
• MMS 22-A-5V
• FPS-S 13
In order to operate the sensor, special housing variants of the grip-
per are required for the sizes MPG-plus 20–32. For the sizes MPG-
plus 40–64, there is a bracket required.
NOTICE
Risk of damage to the sensor during assembly!
• Observe the maximal tightening torque.
5.3.8.1 Mounting the MMS 22-A-5V
Note: In order to mount the sensor MMS 22-A-5V, no additional
attachment kit is required.
Ø Assembling the sensor, Link Analogen Magnetsensor (MMS 22-
A) montieren .
Ø Connect the control unit output and adjust the sensor (see as-
sembly and operating manual of the sensor).
