Maintenance
42
08.00 | MPG-plus | Assembly and operating manual | en | 0389216
7.4 Servicing the gripper
WARNING
Risk of injury due to spring forces!
In case of the variant with "gripping force maintenance", the
cover may be ejected due to high spring forces.
• Carefully disassemble the product.
Ø Clean all parts thoroughly and check for damage and wear.
Ø Oil or grease bare external steel parts.
Ø Disassemble the gripper.
Ø Treat all greased areas with lubricant.Lubricants/Lubrication
points (basic lubrication) [
}
41]
Ø Replace all wear parts / seals.– Position of the wearing parts,
Drawings [
}
43].
– Seal kit, Sealing kit [
}
7].
Ø Assemble the gripper in reverse order. While assembling, pay
attention to the following:
Unless otherwise specified, secure all screws and nuts with Loc-
tite no. 243 and tighten with the appropriate tightening torque.
