SCHUNK ROTA THW plus Series User Manual

Chuck mounts and Spare parts
40 01.00|ROTA THWplus |en
Item
Designation
Quantity
11
Pin
3
12
Thrust bolt
3
13
Spring bolt
3
14
Safety bolt
3
15
Plunger pin
3
16
Pressure piece
6
17
Retainer ring (size 260/315 only)
1
18
Center sleeve (size 260/315 only)
1
19
Assembly tool
1
20
Lever for assembly tool
1
29
Center sleeve seal (from size 250)
1
31
Piston seal
1
32
Adapter seal
1
33
Jaw-change bolt seal
3
34
Compression spring for pressure piece
6
35
Compression spring for safety bolt
3
36
Compression spring for thrust bolt
3
37
Steel ball for jaw-change bolt
3
39
Tapered lubricating nipple
3
40
Mounting screws DIN EN ISO 4762-10.9
3
41
Mounting screws DIN EN ISO 4762-10.9
3
42
Mounting screws DIN EN ISO 4762-10.9
3
43
Mounting screws DIN 7984-8.8
3
44
Mounting screws DIN EN ISO 4762-10.9
3
47
Compression spring for grid
2
48
Steel ball for grid
2
60
Eye bolt
1
90
Jaw change key
1
91
Cross handle for jaw change key
1
93
Holding piece
1
94
Spring sleeve
1
95
Pressure sleeve
1
96
Compression spring for jaw change key
1
