10. When ro tor blades have stopped turn ing, clear air craft as
quickly as pos si ble.
3-6. TRANS MIS SION WARNING/CAU TION IN DI CA TORS
Main Ro tor Trans mis sion
1. Trans mis sion Oil Tem per a ture and Pres sure.
(Fig ure 3-1 &
3-1A) A red warn ing light (M/R XMSN TEMP/PRESS) on the
in stru ment panel co mes on when trans mis sion oil pres sure drops
be low 2-1/2 psi or tem per a ture ex ceeds 235°F.
a. Land as soon as pos si ble if light co mes on in flight.
2. Op tional Chip De tec tor Cau tion In di ca tor (If In stalled). (Fig ure
3-1) An am ber cau tion light (M/R XMSN CHIPS) on the in stru -
ment panel co mes on to in di cate pos si ble de te ri o ra tion of com -
po nents within the main ro tor trans mis sion.
a. Land as soon as pos si ble if light co mes on in flight.
Tail Ro tor Trans mis sion
1. Chip De tec tor Cau tion In di ca tor.
(Fig ure 3-1) An am ber cau tion
light (T/R XMSN CHIPS) on the in stru ment panel co mes on to
in di cate pos si ble de te ri o ra tion of com po nents within the tail ro -
tor trans mis sion.
a. Land as soon as pos si ble if light co mes on in flight.
3-7. FUEL LOW, CAU TION IN DI CA TOR
1. An am ber fuel low cau tion light (FUEL LOW) on the in stru ment
panel co mes on in flight when ap prox i mately one gal lon of us -
able fuel re mains in the tank.
2. If fuel low cau tion light co mes on dur ing flight, land im me di -
ately.
CAU TION
Do not use fuel low cau tion light as a working in di -
ca tion of fuel quan tity (flight time re maining).
Emergency Procedures
Pilot's Flight Manual
Reissued: 16 Jan 2019 3-3
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
