SERVICE TRAINING
Service Manual
20
Rock Valve
Lining
O-Ring
7. Free the lining from the End Cover, and
remove it. It is heavy...get help if needed
8. Thoroughly clean the entire area that the
Outlet Housing Lining touches.
9. Fit a new O-ring into the replacement lining,
and reassemble by following steps 1-7 in
reverse order.
