SERVICE TRAINING
Service Manual
21
Rock Valve
Connection Piece
Cover Lining
Replacement of Outlet
Insert (Cover Lining)
(To be replaced at the same time as the Kidney
Seal and/or Outlet Housing Lining.)
1. Remove the Tapered-Bend (Reducing
Elbow) from the Pipe Bend (Connection
Piece).
2. Remove the Outlet Housing Lining (Kidney
Plate) as described in the
Replacement
of
Outlet Housing Lining
section.
3. Remove the Pipe Bend from the End Cover.
4. Press out the Cover Lining.
To Next Page
